70
Installation GRS103
Release
01
03/2022
M-FAST-SFP-SM+/LC... SM 1310 nm 9/125 µm 10 dB ... 29 dB 25 km ... 65 km
(15.53 mi ... 40.39 mi)
0.4 dB/km 3.5 ps/(nm×km)
M-FAST-SFP-LH/LC... SM 1550 nm 9/125 µm 10 dB ... 29 dB 47 km ... 104 km
(29.20 mi ... 64.62 mi)
0.25 dB/km 19 ps/(nm×km)
M-FAST-SFP-LH/LC... SM 1550 nm 9/125 µm 10 dB ... 29 dB 55 km ... 140 km
(14.29 mi ... 86.99 mi)
0.18 dB/km
c
18 ps/(nm×km)
SFP-FAST-MM/LC
d
MM 1310 nm 50/125 µm 0 dB ... 8 dB 0 km ... 5 km
(0 mi ... 3.11 mi)
1.0 dB/km 800 MHz×km
SFP-FAST-MM/LC EEC
d
MM 1310 nm 62.5/125 µm 0 dB ... 11 dB 0 km ... 4 km
(0 mi ... 2.49 mi)
1.0 dB/km 500 MHz×km
SFP-FAST-SM/LC
d
SM 1310 nm 9/125 µm 0 dB ... 13 dB 0 km ... 25 km
(0 mi ... 15.53 mi)
0.4 dB/km 3.5 ps/(nm×km)
SFP-FAST-SM/LC EEC
d
SM 1310 nm 9/125 µm 0 dB ... 13 dB 0 km ... 25 km
(0 mi ... 15.53 mi)
0.4 dB/km 3.5 ps/(nm×km)
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
b. Including 3 dB system reserve when compliance with the fiber data is observed.
c. With ultra-low-loss optical fiber.
d. You will find further information on certifications on the Internet on the Hirschmann product pages (www.hirschmann.com).
Product code Mode
a
Wave length Fiber System
attenuation
Example for F/O line
length
b
Fiber
attenuation
BLP/Dispersion
Table 23: F/O port 100BASE-FX (SFP Fiber Optic Fast Ethernet Transceiver)
