Hirschmann GRS103 Series User Manual

64
Installation GRS103
Release 01 03/2022
12.3 Power consumption/power output
Connection type 3-pin terminal block
Tightening torque 0.34 Nm (3 lb-in)
min. conductor diameter 1 mm² (AWG16)
max. conductor diameter 1.3 mm² (AWG16)
Rated power 2.5 A
Rated voltage range Type 2 PD, SELV/ES1 54 V DC
Voltage range including maximum
tolerances
51 V DC ... 57 V DC
Overload current protection on the
device
Non-replaceable fuse
Device/module Max. power consumption Max. power output
Basic devices
GRS103-6TX/4C-1HV-2S
a
a. Basic device without media modules.
7.2 W 24.6 Btu (IT)/h
GRS103-6TX/4C-1HV-2A
a
7.2 W 24.6 Btu (IT)/h
GRS103-6TX/4C-2HV-2S
a
7.3 W 26.9 Btu (IT)/h
GRS103-6TX/4C-2HV-2A
a
7.3 W 26.9 Btu (IT)/h
GRS103-22TX/4C-1HV-2S 11.3 W 38.5 Btu (IT)/h
GRS103-22TX/4C-1HV-2A 11.3 W 38.5 Btu (IT)/h
GRS103-22TX/4C-2HV-2S 11.5 W 39.3 Btu (IT)/h
GRS103-22TX/4C-2HV-2A 11.5 W 39.3 Btu (IT)/h
Media modules
M1-8TP-RJ45 2 W 7 Btu (IT)/h
M1-8TP-RJ45 PoE
- internal supply voltage
2.2 W 7.6 Btu (IT)/h
M1-8TP-RJ45 PoE
- external PoE voltage:
No PD
1.2 W 4.1 Btu (IT)/h
M1-8TP-RJ45 PoE
- external PoE voltage:
8 × Class-0-PD
2 W + PDs 6.9 Btu (IT)/h
M1-8MM-SC 10 W 34 Btu (IT)/h
M1-8SM-SC 10 W 34 Btu (IT)/h
M1-8SFP (incl. SFPs) 11 W 37 Btu (IT)/h
Table 16: Power, temperature and order numbers
