Installation GRS103
Release
01
03/2022
63
12.1.2 Media modules
12.2 Supply voltage
12.2.1 Basic device
12.2.2 Media modules
M1-8TP-RJ45 PoE
Dimensions See “Dimension drawings” on page 66.
Weight M1-8TP-RJ45 210 g (0.46 lb)
M1-8MM-SC 210 g (0.46 lb)
M1-8SM-SC 180 g (0.4 lb)
M1-8SFP 130 g (0.29 lb)
M1-8TP-RJ45 PoE 260 g (0.57 lb)
Installing the media modules Tightening torque 0.34 Nm (3 lb-in)
Mounting of the cover panel Tightening torque 0.34 Nm (3 lb-in)
Max. PoE power Per media module: 124 W
Pollution degree 2
Protection classes Laser protection Class 1 in compliance with
IEC 60825-1
Nominal voltage 100 V AC ... 240 V AC, 50 Hz ...60 Hz
Voltage range incl. maximum
tolerances
90 V AC ... 264 V AC, 50 Hz ... 60 Hz
Connection type Built-in non-heating-appliance connection (built-in C14 plug
according to IEC 60320-1)
Minimum conductor diameter 0.75 mm² (AWG18)
Maximum conductor diameter 2.5 mm² (AWG12)
Power loss buffer 115 V AC: >15 ms
230 V AC: >78 ms
Back-up fuse for each voltage
input
Supply voltage 110 V AC
Nominal rating:
Characteristic:
20 A
slow blow
Back-up fuse for each voltage
input
Supply voltage 230 V AC
Nominal rating:
Characteristic:
16 A
B
Overload current protection on
the device
Non-replaceable fuse
Peak inrush current <18 A at 115 V AC
<35A at 230VAC
Table 15: Basic device: Supply voltage
Rated voltage range Type 1 PD, SELV/ES1 48 V DC
Voltage range including maximum
tolerances
45 V DC ... 57 V DC
