Items Specifications
- Electrical x8/Physical x8 Maximum: 25 W
(PCI expansion blade ((x8 FH 2slot)))
I/O adapter slot 2/
slot 3
- Electrical x8/Physical x8; Maximum: 25 W
(PCI blade card adapter x8 L/P)
- Electrical x4/Physical x8; Maximum: 25 W
(PCI blade card adapter x4 L/P)
I/O adapter slot 4/
slot 5
Electrical x4/Physical x8; Maximum: 25 W
Mezzanine
card slot
Number of slots 1
DC input supply voltage DC + 12 V
Power consumption
294 W
1
External dimensions
(width x depth x height)
215.4 mm x 492.7 mm x 51.1 mm
2
Weight
Maximum: 9.54 kg
3
Notes:
1. This value is for a single PCI expansion blade.
2. The shelf is not included in external dimensions.
3. This value includes the shelf for a PCI expansion blade.
Specifications of switch modules
The following table shows the specifications of switch modules.
Table A-15 Specifications of the 1/10Gb LAN switch module
Item Specifications
Interfaces Internal port SerDes 1000Base-X×28 port (default:14 port)
External port RJ-45 10Base-T/100Base-Tx/1000Base-
T×20 port (default:10 port)
10GBASE-SR (SFP+)×4 port (default:0
port)
Management LAN
port
SerDes 1000Base-X×2 port (for connecting
management modules)
RS232C Serial port×1port (Connector:
mini-USB)
1
Layer 2
functionality
VLAN VLAN(IEEE802.1Q)
Private VLAN
Spanning Tree
Protocol (STP)
STP(IEEE802.1D)
RSTP(IEEE802.1w)
A-12
System Unit Specifications
Hitachi Compute Blade 2500 Series Getting Started Guide
