4 Electrical wiring
141
4
SMGB0077 rev.0 - 01/2013
RPI-(2.0-6.0)FSN4E. Terminal board connections
Nº Part
1 Printed circuit board 1 (PCB1)
2 Printed circuit board 2 (PCB2).
3 Terminal board (TB)
3
RPI-(8.0/10.0)FSN3E Terminal board connections
Nº Part
PCB1 Printed circuit board.
PCB2 Printed circuit board.
TF Transformer.
TB3 Terminal strip.
FUSE Fuse
