10 Servicing
311
10
SMGB0077 rev.0 - 01/2013
10.1.9 Removing Float Switch
1 (1) Remove the drain pan according to the item “Removing
Drain Pan”.
2 (2) Remove the insulation which attaches the wires for oat
switch and drain-up mechanism together.
3 (3) Cut the plastic band xing the wires at the xing plate for
oat switch.
4 (4) Removing Float Switch
The oat switch is attached next to the drain-up mechanism.
Remove the oat switch by loosening the xing screw for the
xing base.
N O T E
When reassembling, wrap upthe wiresfor oatswitch and
drain-up mechanism together by the insulation. Fix securely
them to the original position. When attaching the drain pan
again, pay attention not to pull the wires strongly. Otherwise,
the insulation attaching at the cabinet may be peeled.
N O T E
Pay attention to handle the oat switch. If it is
dropped to a oor, the malfunction may occur.
Whenattachingtheoatswitch,tightenthescrewbyhand.
(Do not use a motor-driven screwdriver.)
Float Switch
Plastic Band
Lead Wires
Nut
Fixing Plate for
Float Switch
Screw for
Fixing Plate
To Next Page
