5 Control system
201
5
SMGB0077 rev.0 - 01/2013
5.2 Safety protection and control
Compressor protection
The compressor is protected by the following devices:
• High pressure switch: this stops the compressor when the discharge pressure exceeds the set value.
• Oil heater: this prevents oil from being lost during cold starts, as it is enabled while the compressor is at a standstill.
• Fan motor protection: internal thermostat located in the fan motor winding. This stops the fan motor when the winding
temperature exceeds the set value.
Setting control and safety devices for indoor units
Model RCI-(1.0-3.0)FSN3 RCI-(4.0-6.0)FSN3 RCI-FSN3Ei RCIM-FSN2 RCD
For the evaporator
fan motor: internal
thermostat
Switch
off
ºC 100±4 100
-10
/
+15
145±5 145±5 130±5
Switch
on
ºC 90±4 100
-10
/
+15
90±15 90±15 83±15
For the control circuit:
fuse capacity
- A 5 5 5 5 5
Model RPC RPI(M) RPK RPF(I)
For the evaporator
fan motor: internal
thermostat
Switch
off
ºC 135±5 - 130±5 130±5
Switch
on
ºC 90±15 - 83±15 93±15
For the control
circuit: fuse capacity
- A 5 6,3 5 5
