6 Optional functions
211
6
SMGB0077 rev.0 - 01/2013
Indication Input signal Application Remote control screen (input signal) Port
05
Function 2: unit stoppage
(by pulse)
This signal controls the
stoppage of the system
from a remote location.
N O T E
It is extremely practical
in hotels and ofces
to control the indoor
units from the building
management system.
CN3
06
Cancellation of commands
from the remote control
after a forced stoppage
This signal stops the
indoor unit and cancels the
commands from the remote
control while it is enabled.
CN3
07
Cooling or heating mode
setting
This function controls
operating mode changes
from a remote location.
CN3
08
Up/down input signal for
grille (not available)
Not available
CN3
