9 Spare parts
293
9
SMGB0077 rev.0 - 01/2013
Number Part name Remarks
U00 Terminal board —
U02 Remote control switch PC-P2HTE/PC-ART
U12 Exp. valve cord —
U13 Exp. valve cord —
U14 Capacitor 2μF / 4μF
U15A Thermistor THM1 Air Inlet
U15B Thermistor THM5 Gas
U15C Thermistor THM3 Liquid (freeze protection)
U15D Thermistor THM2 Air Outlet
U21 Expansion valve —
U31 Air lter —
U34A D grille Air outlet
U34B Air inlet grille Air inlet
U34C Air inlet grille Air inlet
U36 Runner —
U37 Fan casing —
U41 Heat exchanger Assembly
U65A Spacer For îš¿xing PCB
U65B Push spacer For îš¿xing PCB
U65C Grille knob —
U71 Fan motor —
U82 Transformer —
U85 Printed circuit board —
U98A Back cover Assembly
U98B Front cover Assembly
U98C Side cover Assembly
U98D Upper cover —
