9 Spare parts
295
9
SMGB0077 rev.0 - 01/2013
Number Part name Remarks
U00 Printed circuit board terminals —
U02 SW remote control PC-P2HTE/PC-ART (optional)
U12 Cord expansion valve —
U13 Cord expansion valve —
U14 Capacitor 2uF/4uF
U15A Thermistor THM1 thermistor for air inlet
U15B Thermistor THM5 thermistor for gas pipe
U15C Thermistor THM3 thermistor for liquid piping
U15D Thermistor THM2 thermistor for air outlet
U21 Expansion valve —
U31 Air lter —
U36 Runner —
U37 Fan frame —
U41 Heat exchanger Assembly
U65A Spacer Attached to the PCB
U65B Push spacer Attached to the PCB
U71 Fan motor —
U82 Transformer —
U85 Printed circuit board —
U98A Rear cover Assembly
U98B Front cover Assembly
