Hitachi RPI-2.0FSN4E Service Manual

2 Unit installation
SMGB0077 rev.0 - 01/2013
37
2
S
space around the unit for installation and maintenance.
Install a service hatch near the pipe connection area and electrical junction box for installation and maintenance work.
1. Piping connection.
2. Wall.
3. Service access panel.
3
1
3
1
2
Check that the ceiling surface where the air panel is to be installed is completely horizontal.
Check that the drain hose can be installed maintaining the necessary down-slope.
Installation
Cut the area of the unit in the false ceiling and reinforce the
opening made.
Install the M10 (3/8”) suspension bolts depending on the
type of surface:
Model A (Opening) B (Suspension)
RCD-1.0
1060 890
RCD-1.5
RCD-2.0
RCD-2.5
RCD-3.0
RCD-4.0
1620 1450
RCD-5.0
1 Suspension
2 Panel
3 Wireless receiver
4 Piping
540mm
670mm
A
B
1
2
4
4
3
Concrete beams
1 150 to 160 mm
2 Steel
3 Anchor bolt (W3/8 or M10)
4 Concrete
5 Insert (100 to 150 kg)
1
2
3
4
5
