Hitachi RPI-2.0FSN4E Service Manual

2 Unit installation
42
SMGB0077 rev.0 - 01/2013
Electrical connection of the air panel
C A U T I O N
Switch off the power supply to the unit before coupling the connectors, otherwise the automatic louver will not
work.
The following connector is used with the air panel (see from the
lower surface of the air panel without the air inlet grille).
Couple the connectors as indicated in the gure (view of the
electrical box from above).
