Pn No.
Size
Name
Setting range
Setting Unit
Factory
setting
Available
time
Categ
ory
Model
Pn50A
2
Input signal selection 1
0000～9991
-
1801 (axis A)
5841 (axis b)
Power
restart
Setup
P
0801 (axis A)
0841 (axis b)
B
n.

X
Allocation mode of input signals
Remarks
0
Appointment Parameters (Do Not Set)
1
According to different signals.
n.X
Allocation of servo ON input (/S-ON) signal
Remarks
0
CN1-IN0 takes effect when the input signal is ON.
1
CN1-IN1 takes effect when the input signal is ON.
2
CN1-IN2 takes effect when the input signal is ON.
3
CN1-IN3 takes effect when the input signal is ON.
4
CN1-IN4 takes effect when the input signal is ON.
5
CN1-IN5 takes effect when the input signal is ON.
6
CN1-IN6 takes effect when the input signal is ON.
7
CN1-IN7 takes effect when the input signal is ON.
8
Fixed the signal as "invalid" all the time.
9
Set the signal to "active" at all times.
n.

X

P action command input (/P-CON) signal distribution
Remarks
0～9
Same distribution as servo on input (/S-ON) signal.
n.X
Prohibit forward rotation side drive input (P-OT) signal allocation
Remarks
0
When the input signal of CN1-IN0 is ON (closed), forward rotation side
drive can be performed.
1
When the input signal of CN1-IN1 is ON (closed), forward rotation side
drive can be performed.
2
When the input signal of CN1-IN2 is ON (closed), forward rotation side
drive can be performed.
3
When the input signal of CN1-IN3 is ON (closed), forward rotation side
drive can be performed.
4
When the input signal of CN1-IN4 is ON (closed), forward rotation side
drive can be performed.
5
When the input signal of CN1-IN5 is ON (closed), forward rotation side
drive can be performed.
6
When the input signal of CN1-IN6 is ON (closed), forward rotation side
drive can be performed.
7
When the input signal of CN1-IN7 is ON (closed), forward rotation side
drive can be performed.
8
The signal is always fixed as "forward rotation side drivable".
9
The signal is always fixed as "No Forward Turn Side Drive".
Pn50B
2
Input signal selection 2
0000～9999
-
8832 (axis A)
8876 (axis b)
Power
restart
Setup
P
8881 (axis A)
8885 (axis b)
B
n.X
Prohibit reverse rotation side drive input (P-OT) signal allocation
Remarks
0
When the input signal of CN1-IN0 is ON (closed), reverse rotation side
drive can be performed.
1
When the input signal of CN1-IN1 is ON (closed), reverse rotation side
drive can be performed.
2
When the input signal of CN1-IN2 is ON (closed), reverse rotation side
drive can be performed.
3
When the input signal of CN1-IN3 is ON (closed), reverse rotation side
drive can be performed.
4
When the input signal of CN1-IN4 is ON (closed), reverse rotation side
drive can be performed.
5
When the input signal of CN1-IN5 is ON (closed), reverse rotation side
drive can be performed.
6
When the input signal of CN1-IN6 is ON (closed), reverse rotation side
drive can be performed.
7
The signal is always fixed as "No reversal Turn Side Drive".
8
The signal is always fixed as "reverse rotation side drivable".
9
When the input signal of CN1-IN0 is OFF (cut off), reverse rotation side
drive can be performed.
n.X
Assignment of Alarm Reset Input (/ALM-RST) Signal
Remarks
0
The input signal of CN1-IN0 is valid from the edge of OFF(cut off) to
ON(closed).
1
The input signal of CN1-IN1 is valid from the edge of OFF(cut off) to
ON(closed).
2
The input signal of CN1-IN2 is valid from the edge of OFF(cut off) to
ON(closed).
3
The input signal of CN1-IN3 is valid from the edge of OFF(cut off) to
ON(closed).
4
The input signal of CN1-IN4 is valid from the edge of OFF(cut off) to
ON(closed).
5
The input signal of CN1-IN5 is valid from the edge of OFF(cut off) to
ON(closed).
6
The input signal of CN1-IN6 is valid from the edge of OFF(cut off) to
ON(closed).
7
The input signal of CN1-IN7 is valid from the edge of OFF(cut off) to
ON(closed).
8
Fixed the signal as "invalid" all the time.
9
Appointment Parameters (Do Not Set)
n.X
Distribution of external torque limit input（/P-CL） signal on forward rotation side)
Remarks
0～9
Same distribution as servo on input (/S-ON) signal.
n.X
Distribution of external torque limit input(/P-CL) signal on reverse rotation side)
Remarks
0～9
Same distribution as servo on input (/S-ON) signal.
