97
Pn No.
Size
Name
Setting range
Setting
Unit
Factory setting
Available
time
Categor
y
Rema
rks
Pn50C
2
Input signal selection 3
00009999
-
8888
Power
restart
Setup
-
n.X
Distribution of motor rotation direction switching input (/SPD-D) signal
Remarks
0
CN1-IN0 takes effect when the input signal is ON.
1
CN1-IN1 takes effect when the input signal is ON.
2
CN1-IN2 takes effect when the input signal is ON.
3
CN1-IN3 takes effect when the input signal is ON.
4
CN1-IN4 takes effect when the input signal is ON.
5
CN1-IN5 takes effect when the input signal is ON.
6
CN1-IN6 takes effect when the input signal is ON.
7
CN1-IN7 takes effect when the input signal is ON.
8
Fixed the signal as "invalid" all the time.
9
Set the signal to "active" at all times.
n.X
Internal setting speed switching input (/SPD-A) signal distribution
Remarks
09
The distribution of signals is the same as that of motor rotation
direction switching input (/SPD-D).
n.X
Rotation detection output/TGON signal distribution
Remarks
09
The distribution of signals is the same as that of motor rotation
direction switching input (/SPD-D).
n.X

The control mode switches the distribution of input (/C-SEL) signals
Remarks
09
The distribution of signals is the same as that of motor rotation direction
switching input (/SPD-D).
Pn50D
2
Input signal selection 4
00000999
-
0888
Power
restart
Setup
-
n.X
Zero position fixing input signals
Remarks
0
CN1-IN0 takes effect when the input signal is ON.
1
CN1-IN1 takes effect when the input signal is ON.
2
CN1-IN2 takes effect when the input signal is ON.
3
CN1-IN3 takes effect when the input signal is ON.
4
CN1-IN4 takes effect when the input signal is ON.
5
CN1-IN5 takes effect when the input signal is ON.
6
CN1-IN6 takes effect when the input signal is ON.
7
CN1-IN7 takes effect when the input signal is ON.
8
Fixed the signal as "invalid" all the time.
9
Set the signal to "active" at all times.
n.X
The command pulse prohibits the distribution of the input (/INHIBIT) signal
Remarks
09
Same distribution as zero position fixing input signals
n.X
Distribution of gain switching input(/ G-SEL) signals
Remarks
09
Same distribution as zero position fixing input signals
n.X
Appointment parameters (do not change it)
Pn50E
2
Output signal selection 1
00006666
-
6611 (axis A)
6644 (axis b)
Power
restart
Setup
-
n.X
Positing complete output(/COIN) signal distribution
Remarks
0
The above signals are output from CN1-OUT0 (7, 8) output terminals.
1
The above signals are output from CN1-OUT1 (9, 10) output terminals.
2
The above signals are output from CN1-OUT2 (11, 12) output terminals.
3
The above signals are output from CN1-OUT3 (32, 33) output
terminals.
4
The above signals are output from CN1-OUT4 (34, 35) output
terminals.
5
The above signals are output from CN1-OUT5 (36, 37) output
terminals.
6
Invalid (not using the above signal output).
n.

X
Distribution of speed consistent output (/V-CMP) signal
Remarks
06
Same as positing complete output(/COIN) signal distribution
n.X
Rotation detection output/TGON signal distribution
Remarks
06
Same as positing complete output(/COIN) signal distribution
n.X

Distribution of servo ready output (/S-RDY) signal
Remarks
06
Same as positing complete output(/COIN) signal distribution
