HNC Electric HSD7-E Series - Page 105

99
Pn No.
Size
Name
Setting range
Setting
Unit
Factory
setting
Available
time
Categor
y
Model
Pn511
2
Input signal selection 4
0000～9999
-
8888
Power
restart
Setup
P
8836 (axis A)
8872 (axis b)
B
n.X
Distribution of input (/DEC) signal of origin reset deceleration switch
0
CN1-IN0 takes effect when the input signal is ON.
1
CN1-IN1 takes effect when the input signal is ON.
2
CN1-IN2 takes effect when the input signal is ON.
3
CN1-IN3 takes effect when the input signal is ON.
4
CN1-IN4 takes effect when the input signal is ON.
5
CN1-IN5 takes effect when the input signal is ON.
6
CN1-IN6 takes effect when the input signal is ON.
7
CN1-IN7 takes effect when the input signal is ON.
8
Fixed the signal as "invalid" all the time.
9
Set the signal to "active" at all times.
n.X
Distribution of external latch input 1 (/EXT1) signal
0～4
Fixed the signal as "invalid" all the time.
5
CN1-IN5 takes effect when the input signal is ON.
6
CN1-IN6 takes effect when the input signal is ON.
7
CN1-IN7 takes effect when the input signal is ON.
8～C
Fixed the signal as "invalid" all the time.
D
CN1-IN5 is valid when the input signal is OFF(cut off).
E
CN1-IN6 is valid when the input signal is OFF(cut off).
F
CN1-IN7 is valid when the input signal is OFF(cut off).
n.X
Distribution of external latch input 2 (/EXT2) signal
0～F
Same distribution as external latch input 1(/EXT1) signal.
n.X
Distribution of external latch input 3 (/EXT3) signal
0～F
Same distribution as external latch input 1(/EXT1) signal.
Pn512
2
Output signal inversion
setting 0
0000～1111
-
0000
Power
restart
Setup
-
n.X
CN1-OUT0 (7, 8) terminal output signal inversion
0
Not reverse signal.
1
Reverses the signal.
n.X
CN1-OUT1 (9, 10) terminal output signal inversion
0
Not reverse signal.
1
Reverses the signal.
n.X
CN1-OUT2 (11, 12) terminal output signal inversion
0
Not reverse signal.
1
Reverses the signal.
n.X
CN1-OUT3 (32, 33) terminal output signal inversion
0
Not reverse signal.
1
Reverses the signal.
Pn513
2
Output signal inversion
setting 1
0000～0011
-
0000
Power
restart
Setup
-
n.

X
CN1-OUT4 (34, 35) terminal output signal inversion
0
Not reverse signal.
1
Reverses the signal.
n.

X

CN1-OUT5 (36, 37) terminal output signal inversion
0
Not reverse signal.
1
Reverses the signal.
n.

X

Appointment parameters (do not change it)
n.X
Appointment parameters (do not change it)
