103
Pn No.
Size
Name
Setting range
Setting Unit
Factory
setting
Available
time
Categ
ory
Rema
rks
Pn80A
2
Section 1 linear
acceleration parameters
1～65535
10000
Command
unit/s
2
100
Effective
immediately
*5
Setup
Pn80B
2
Section 2 linear
acceleration parameters
1～65535
10000
Command
unit/s
2
100
Effective
immediately
*5
Setup
Pn80C
2
Accelerating parameter
switching speed
0～65535
10000
Command
unit/s
2
0
Effective
immediately
*5
Setup
Pn80D
2
Section 1 linear
deceleration parameters
1～65535
10000
Command
unit/s
2
100
Effective
immediately
*5
Setup
Pn80E
2
Section 2 linear
deceleration parameters
1～65535
10000
Command
unit/s
2
100
Effective
immediately
*5
Setup
Pn80F
2
Deceleration parameter
switching speed
0～65535
10000
Command
unit/s
2
0
Effective
immediately
*5
Setup
Pn810
2
Exponential function
acceleration and
deceleration bias
0～65535
10000
Command
unit/s
2
0
Effective
immediately
Setup
Pn811
2
Parameters of exponential
function during
acceleration and
deceleration
0～5100
0.1 ms
0
Effective
immediately
Setup
Pn812
2
Average moving time
0～5100
0.1 ms
0
Effective
immediately
Setup
Pn814
4
External positioning final
movement distance
-1073741823～
1073741823
1
Command
unit
100
Effective
immediately
Setup
Pn816
M2
2
Setting of origin reset
mode
0000～0001
-
0000
Effective
immediately
Setup
*7
n.

X
Origin reversion direction
0
Set to forward direction.
1
Set to reverse direction.
n.X
Appointment parameters (do not change it)
n.

X

Appointment parameters (do not change it)
n.X
Appointment parameters (do not change it)
Pn817
*8
2
Home reset approach
speed 1
0～65535
10000
Command
unit/s
2
50
Effective
immediately
*5
Setup
Pn818
2
Home reset approach
speed 2
0～65535
10000
Command
unit/s
2
5
Effective
immediately
*5
Setup
Pn819
4
Origin reset final move
distance
-1073741823～
1073741823
1
Command
unit
100
Effective
immediately
Setup
Pn81E
M2
2
Input signal monitoring
Selection
0000～7777
-
0000
Effective
immediately
Setup
*7
n.X
IO-12 allocation
0
No distribution
1
Monitor CN1-IN0 input terminals.
2
Monitor CN1-IN1 input terminals.
3
Monitor CN1-IN2 input terminals.
4
Monitor CN1-IN3 input terminals.
5
Monitor CN1-IN4 input terminals.
6
Monitor CN1-IN5 input terminals.
7
Monitor CN1-IN6 input terminals.
n.

X

IO-13 allocation
0～7
The allocation is the same as IO-12.
n.X
IO-14 allocation
0～7
The allocation is the same as IO-12.
n.X

IO-15 allocation
0～7
The allocation is the same as IO-12.
