HNC Electric HSD7-E Series - Automatic Adjustment Steps and Settings

105
Pn No.
Size
Name
Setting range
Setting Unit
Factory
setting
Available
time
Categ
ory
Remar
ks
Pn825
2
Option monitoring 2
selection
0000〜FFFF
-
0000
Effective
immediately
Setup
Setting value
Monitoring function
0000H～
0084H
Same as option monitoring 1.
Pn827
2
Stop using linear
deceleration parameter 1
1～65535
10000
Command
unit/s
2
100
Effective
immediatel
y
*5
Setup
Pn829
2
SVOFF wait time
(when deceleration stops
SVOFF)
0～65535
10 ms
0
Effective
immediatel
y
*5
Setup
Pn82A
M2
2
OPTION bit field function
allocation
0000～1E1E
-
1813
Power
restart
Setup
*7
n.X
ACCFIL allocation (OPTION)
0
Set ACCFIL to be bits 0 and 1.
1
Set ACCFIL to be bits 1 and 2.
2
Set ACCFIL to be bits 2 and 3.
3
Set ACCFIL to be bits 3 and 4.
4
Set ACCFIL to be bits 4 and 5.
5
Set ACCFIL to be bits 5 and 6.
6
Set ACCFIL to be bits 6 and 7.
7
Set ACCFIL to be bits 7 and 8.
8
Set ACCFIL to be bits 8 and 9.
9
Set ACCFIL to be bits 9 and 10.
A
Set ACCFIL to be bits 10 and 11.
B
Set ACCFIL to be bits 11 and 12.
C
Set ACCFIL to be bits 12 and 13.
D
Set ACCFIL to be bits 13 and 14.
E
Set ACCFIL to be bits 14 and 15.
n.

X

Valid/invalid selection of ACCFIL allocation
0
Make ACCFIL bit allocation invalid.
1
Make ACCFIL bit allocation valid.
n.X
Allocation of G_SEL(OPTION)
0～E
The allocation is the same as ACCFIL.
n.X
Valid/invalid selection of G_SEL allocation
0
Make G_SEL bit allocation invalid.
1
Make G_SEL bit allocation valid.
Pn82B
M2
2
OPTION area function
allocation 2
0000～1F1F
-
1D1C
Power
restart
Setup
*7
n.X
V_PPI allocation (OPTION)
0
Set V_PPI to bit 0.
1
Set V_PPI to bit 1.
2
Set V_PPI to bit 2.
3
Set V_PPI to bit 3.
4
Set V_PPI to bit 4.
5
Set V_PPI to bit 5.
6
Set V_PPI to bit 6.
7
Set V_PPI to bit 7.
8
Set V_PPI to bit 8.
9
Set V_PPI to bit 9.
A
Set V_PPI to bit 10.
B
Set V_PPI to bit 11.
C
Set V_PPI to bit 12.
D
Set V_PPI to bit 13.
E
Set V_PPI to bit 14.
F
Set V_PPI to bit 15.
n.X
Valid/invalid selection of V_PPI allocation
0
Make V_PPI bit allocation invalid.
1
Make V_PPI bit allocation valid.
n.

X

Allocation of P_PI_CLR(OPTION)
0～F
The allocation is the same as V_PPI.
n.X
Valid/invalid selection of V_PPI allocation
0
Make P_PI_CLR bit allocation invalid.
1
Make P_PI_CLR bit allocation valid.
