HNC Electric HSD7-E Series - Auto-Tuning Using iWatch+

106
Pn No.
Size
Name
Setting range
Setting Unit
Factory
setting
Available
time
Categor
y
Rema
rks
Pn82C
M2
2
OPTION area function
allocation 3
0000～1F1F
-
1F1E
Power
restart
Setup
*7
n.X
Allocation of P_CL(OPTION)
0～F
The allocation is the same as V_PPI.
n.X
Valid/invalid selection of P_CL allocation
0
Make P_CL bit allocation invalid.
1
Make P_CL bit allocation valid.
n.

X

Allocation of N_CL(OPTION)
0～F
The allocation is the same as V_PPI.
n.X
Valid/invalid selection of N_CL allocation
0
Make N_CL bit allocation invalid.
1
Make N_CL bit allocation valid.
Pn82D
M2
2
OPTION area function
allocation 4
0000～1F1C
-
0000
Power
restart
Setup
*7
n.X
Allocation of BANK_SEL1(OPTION)
0
Set BANK_SEL1 to be bits 0～3.
1
Set BANK_SEL1 to be bits 1～4.
2
Set BANK_SEL1 to be bits 2～5.
3
Set BANK_SEL1 to be bits 3～6.
4
Set BANK_SEL1 to be bits 4～7.
5
Set BANK_SEL1 to be bits 5～8.
6
Set BANK_SEL1 to be bits 6～9.
7
Set BANK_SEL1 to be bits 7～10.
8
Set BANK_SEL1 to be bits 8～11.
9
Set BANK_SEL1 to be bits 9～12.
A
Set BANK_SEL1 to be bits 10～13.
B
Set BANK_SEL1 to be bits 11～14.
C
Set BANK_SEL1 to be bits 12～15.
n.X
Valid/invalid selection of BANK_SEL1 allocation
0
Make BANK_SEL1 bit allocation invalid.
1
Make BANK_SEL1 bit allocation valid.
n.X
Allocation of LT_DISABLE(OPTION)
0～F
The allocation is the same as V_PPI.
n.X
Valid/invalid selection of LT_DISABLE allocation
0
Make LT_DISABLE bit allocation invalid.
1
Make LT_DISABLE allocation valid
Pn82E
M2
2
OPTION area function
allocation 4
0000～1F1C
-
0000
Power
restart
Setup
*7
n.

X
Appointment parameters (do not change it)
n.X
Appointment parameters (do not change it)
n.X
Allocation of OUT_SIGNAL(OPTION)
0
Set OUT_SIGNAL to be bits 0 ~ 2.
1
Set OUT_SIGNAL to be bits 1 ~ 3.
2
Set OUT_SIGNAL to be bits 2 ~ 4.
3
Set OUT_SIGNAL to be bits 3 ~ 5.
4
Set OUT_SIGNAL to be bits 4 ~ 6.
5
Set OUT_SIGNAL to be bits 5 ~ 7.
6
Set OUT_SIGNAL to be bits 6 ~ 8.
7
Set OUT_SIGNAL to be bits 7 ~ 9.
8
Set OUT_SIGNAL to be bits 8 ~ 10.
9
Set OUT_SIGNAL to be bits 9 ~ 11.
A
Set OUT_SIGNAL to be bits 10 ~ 12.
B
Set OUT_SIGNAL to be bits 11 ~ 13.
C
Set OUT_SIGNAL to be bits 12 ~ 14.
D
Set OUT_SIGNAL to be bits 13 ~ 15.
n.X
Valid/invalid selection of OUT_SIGNAL allocation
0
Make OUT_SIGNAL bit allocation invalid.
1
Make OUT_SIGNAL bit allocation valid.
