93
Pn No.
Size
Name
Setting range
Setting Unit
Factory
setting
Available
time
Catego
ry
Rema
rks
Pn302
3
Internal set speed 2
0～10000
1 min
-1
200
Effective
immediately
Setup
Pn303
3
Internal set speed 3
0～10000
1 min
-1
300
Effective
immediately
Setup
Pn304
2
Jog (JOG) speed
0～10000
1 min
-1
500
Effective
immediately
Setup
Pn305
2
Soft start acceleration time
0～10000
1 ms
0
Effective
immediately
Setup
Pn306
2
Soft start deceleration time
0～10000
1 ms
0
Effective
immediately
Setup
Pn307
2
Speed Command filtering
time parameter
0～65535
0.01ms
40
Effective
immediately
Setup
Pn308
2
Time Parameters of Speed
Feedback Filter
0～65535
0.01 ms
0
Effective
immediately
Setup
Pn30A
2
Deceleration Time for
Servo OFF and Forced
Stop
0～10000
1 ms
0
Effective
immediately
Setup
Pn30C
2
Speed feedforward moving
average time
0～5100
0.1 ms
0
Effective
immediately
Setup
Pn310
2
Vibration detection switch
0000～0002
-
0000
Effective
immediately
Setup
-
n.X
Rotation direction selection
0
No vibration is detected.
1
Warning issued after vibration detection (A.911).
2
Alarm is issued after vibration is detected (A.520).
n.X
Appointment parameters (do not change it)
n.

X

Appointment parameters (do not change it)
n.X
Appointment parameters (do not change it)
Pn311
2
Vibration detection
sensitivity
50～500
1%
100
Effective
immediately
Adjust
ment
Pn312
2
Vibration detection value
0～5000
1 min
-1
50
Effective
immediately
Adjust
ment
Pn316
2
Maximum speed of motor
0～65535
1 min
-1
10000
Power
restart
Setup
Pn324
2
Estimated Starting Value of
Moment of Inertia
0～20000
1%
300
Effective
immediately
Setup
Pn400
2
Torque command input
gain
10～100
0.1 V/ Rated
torque
30
Effective
immediately
Setup
Pn401
2
Section 1 First Torque
Command Filter Time
Parameters
0～65535
0.01 ms
100
Effective
immediately
Adjust
ment
Pn402
2
Forward rotation torque
limit
0～800
1%
*1
800
Effective
immediately
Setup
Pn403
2
Reversal torque limit
0～800
1%
*1
800
Effective
immediately
Setup
Pn404
2
External torque limit on
forward rotation side
0～800
1%
*1
100
Effective
immediately
Setup
Pn405
2
Reverse side external
torque limit
0～800
1%
*1
100
Effective
immediately
Setup
Pn406
2
Emergency stop torque
0～800
1%
*1
800
Effective
immediately
Setup
Pn407
2
Speed limit during torque
control
0～10000
1 min
-1
10000
Effective
immediately
Setup
Pn408
2
Torque type function switch
0000～1111
-
0000
-
Setup
-
n.

X
Selection of Notch Filter 1
Available
time
0
Section 1 notch filter is invalid.
Effective
immediately
1
Use the notch filter of section 1.
n.

X

Selection of speed limit
Available
time
0
The speed limit value uses "motor maximum speed", the smaller of
Pn407 settings.
Power
restart
1
The speed limit value uses "speed detected by overspeed alarm", the
smaller of the Pn407 set values.
n.X
Selection of Notch Filter 2
Available
time
0
Section 2 notch filter is invalid.
Effective
immediately
1
Use the notch filter of section 2.
n.X
Frictional compensation Function selection
Available
time
0
The friction compensation function is not used.
Effective
immediately
1
Use friction compensation function.
