INTRODUCTION
And this instrument uses the following markings:
Fuse To identify fuse boxes or their loca-
tion.
IEC 60417 Graphical symbols
for use on equipment, symbol
5016
Waste Electrical and Electronic Equipment
Do not dispose in municipal waste
Contact Hologic for disposal of the instrument
On (Power switch on the microscope)
Off (Power switch on the microscope)
Lamp intensity adjustment
Standby power (computer)
USB port icon (computer)
Ethernet port icon (computer)
Monitor display (computer)
Symbol Title Description Standard information
1
2
3
4
5
6
