OPERATION
4.4
ThinPrep
®
Integrated Imager Operator’s Manual
Important Operational Notes:
• A slide can only be imaged once on an Integrated Imager.
• The mounting medium must be thoroughly dry.
• The label must be appropriate for the ThinPrep
®
Integrated Imager (refer to page 3.14).
• Always keep the instrument in proper Koehler alignment (refer to page 5.2).
• Do not use filters on the collector or in the objectives - this will interfere with correctly imag-
ing the slide.
• During slide imaging keep motion or vibration near the instrument at a minimum.
• A slide must be reviewed on the same Integrated Imager that was used to image it.
• Marking the slide - the slides are manually marked by the CT. Follow your laboratory’s guide-
lines for marking slides. It is recommended that at least Auto Locate is completed prior to
making any physical marks.
• When using Auto Locate, the CT must always examine the entire field of view.
USING THE TOUCH SCREEN AND REVIEW CONTROLS
Touch Screen
The touch screen can be adjusted higher or lower from the desktop by sliding it up or down along its
mounting rail. The screen will stay at the height it is left at. The range is between 5 to 12 inches above
the desktop.
The touch screen horizontal or vertical tilt may be adjusted to fit user preferences. See Figure 4-2.
Turn the adjustment knob to loosen and adjust the tilt, then tighten the knob when the screen is in the
desired position.
