INTRODUCTION
1.14 ThinPrep
®
Integrated Imager Operator’s Manual
1
Location of Labels
Figure 1-7 Location of Labels
Instrument
part number label
Instrument
serial number label
Model/rating label
(includes these marks)
Rear of Instrument (PC removed for clarity.)
PC serial number on top
(not shown)
USB port
Power
Ethernet port
USB port (5)
Front and Rear of Computer
( Note: The number and exact location of ports may be different, depending on the PC model you have.)
