ThinPrep
®
Integrated Imager Operator’s Manual 3.15
3
USER INTERFACE
OCR format must be 14-digits’ long in two rows, 7 digits over 7 digits, with the patient ID being 11
digits and a 3-digit CRC (which cannot be altered by the operator) at the end. The font must be 12
point OCR-A. Numbers only, no alpha characters.
Note: For OCR format, ‘9999’ as the last 4 digits before the CRC are reserved for field service use.
Slide IDs with those reserved numbers are removed from the patient database during a ser
-
vice visit, so do not use that sequence.
Slide barcode labels may be 1- or 2-dimensional. 1-D barcodes must meet ANSI X3.182 specifications
with a quality of grade B or better. See the table below for any restrictions. Slide labels may be
printed and applied or directly printed or etched onto the slide. (See
Figure 3-23.) In any case, make
sure the contrast is sufficient for the scanner to read the label.
Table 3.1: Slide Restrictions Based on Barcode Symbology Used
1-D Code 128 All printable ASCII 128 characters are supported. The barcode width
varies with content. Minimum of 5
characters is required and maxi-
mum of 8 alphas or 14 digits will fit on a slide. Mixing will shorten the
max length.
1-D Interleaved 2 of 5 Only digits are supported. 5,7,9, or 11 characters +1 (optional) check
digit is the format.
1-D Code 39 Supported characters are A–Z, 0–9, - + . $ / % ‘space’ Minimum
of 5
characters is required and maximum of 6 characters will fit on a
slide. (A single character check digit is optional.)
1-D Code 93 All printable ASCII 128 characters are supported. A minimum of
5
characters is required and a maximum of 8 characters will fit on a
slide.
2-D datamatrix All printable ASCII 128 characters are supported. A maximum of
16
characters is supported.
