Trident HD Specimen Radiography System User Guide
Chapter 3: Components, Controls, and Indicators
MAN-05478-002 Revision 003 Page 17
Specimen Tray
The specimen tray has markings to show the center point, the 1.5x magnification
margins, and the 2.0x magnification margins.
Figure 5: Specimen Tray Markings for the Full-Field
Detector
Figure Legend
1. Center
2. 2.0x Magnification Margins
3. 1.5x Magnification Margins
Caution
To prevent damage, use care when handling and cleaning the specimen tray.
Note
Store the specimen tray inside the Imaging Cabinet.
