Hologic Trident HD - Table 3: Filter Tab Options (Require Access Privileges)

Trident HD Specimen Radiography System User Guide
Chapter 4: User Interface
Page 32 MAN-05478-002 Revision 003
Filter Tab
Use the Filter tab to change the filter options for the patient list. When you select or
cancel an option, the change shows in the Results area of the screen.
Note
You must have Manager level access to save these new filters to the selected tab in the
Select Patient screen. (Refer to Other Functions of the Filter Tab on page 32
.)
Note
When you select a line in the results list then select the Open button, the Procedure
screen for the selected patient opens.
Other Functions of the Filter Tab
The Filter tab allows users with access privileges to add, change, or delete tabs in the
Select Patient screen. Refer to the following table.
Table 3:
Filter Tab Options (Require Access Privileges)
Change the current patient
filter parameters.
1. Select a tab on the Select Patient screen.
2. Select the Filter button.
3. Select the filter options.
4. Select the Save button.
5. Make sure the name of the tab you selected is in
the name box.
6. Select OK.
Create a new tab for the Select
Patient screen.
1. Select a tab on the Select Patient screen.
2. Select the Filter button.
3. Select the filter options for the tab.
4. Select the Save As button.
5. Enter a new name for the tab.
6. Select OK.
Delete a tab from the Select
Patient screen.
1. Select a tab on the Select Patient screen.
2. Select the Filter button.
3. Select the Delete button.
4. Select Yes in the confirmation dialog box.
