Trident HD Specimen Radiography System User Guide
Chapter 4: User Interface
MAN-05478-002 Revision 003 Page 37
4.3.4 Close a Patient
Select the Close Patient button. The system returns to the Select Patient screen and
automatically saves to the configured output devices any images that were not sent
previously.
4.3.5 How to Select an Output Group
Select an output device set from the Output Groups drop-down list in the Procedure
screen.
Note
Images are not sent if an Output Group is not selected.
4.4 How to Access Image Review Features
Select the Tools tab in the Procedure screen to access the image review features and tools.
Refer to Tools Tab on page 46
for information.
4.5 How to Use the Output Groups
The images are sent automatically to the output devices in the selected Output Group
when a patient is closed.
4.5.1 Add or Edit an Output Group
Note
The configuration of Output Groups occurs during installation, but you can edit
existing groups or add new groups.
To add a new Output Group:
1. Access the Admin screen.
2. Select the Manage Output Groups button.
3. Select the New button, enter the information, then select the output device(s).
4. Select Add, then select OK in the Update Successful message.
5. You can select any group to set as the default.
To edit an Output Group:
1. Access the Admin screen.
2. Select the Manage Output Groups button.
3. Select the Edit button, then make the changes.
4. Select Save, then select OK in the Update Successful message.
