Trident HD Specimen Radiography System User Guide
Chapter 5: The Images
Page 44 MAN-05478-002 Revision 003
After the exposure ends:
• The image opens on the Image Display monitor and a thumbnail image appears
in the thumbnail area of the Procedure screen. The image is automatically
accepted.
6. To acquire another image, select the X-ray Enable bar, then press the X-RAY button.
To stop an exposure before automatic termination, press the X-RAY button. An error
message is displayed.
To start another exposure after you stopped one before automatic termination:
1. Select OK in the error message.
2. Select the console icon in the taskbar.
3. Select Clear All Faults.
4. Enable the X-ray.
5. Press the X-RAY button.
To delete an image, select the thumbnail image then select the trash can icon.
Note
You cannot restore a deleted image.
Refer to Sample Clinical Sequences on page 51
for additional information.
