Trident User Guide
Chapter 4: The User Interface
MAN-02098 Revision 008 Page 31
4.7 How to Set Up the Specimen Cabinet
1. Open the Cabinet door.
2. Place the specimen.
• For a contact image, put the specimen on the contact surface of the Cabinet.
• For a magnification image, put the specimen on the 1.5X Stage or the 2.0X Stage in
the Cabinet. See the figure Cabinet Components on page 11.
3. Close the Cabinet door.
Note
X-ray is enabled when the door is closed. If the door is
opened during an exposure, the exposure ends
automatically.
4. Turn the Key Switch from the locked position to the unlocked position.
5. Refer to How to Acquire an Image on page 25 for steps about image acquisition.
Note
If you press the X-RAY button to end an exposure, an error
message appears. To start another exposure, select the OK
button then select the status icon in the taskbar at the bottom
of the screen. Select the Clear All Faults option. When
READY shows in the system message area, press the X-RAY
button.
