Chapter 5: The Images
MAN-02098 Revision 008 Page 37
Note
The
Ruler, W/L Presets, and Enhanced Visualization tool are
inactive for snapshot images.
Figure Legend
1. The Mag tool magnifies a section of the image.
2. The Zoom tool magnifies the whole image.
3. The Window/Level tool is used with the mouse to change the brightness and contrast. To
reset the Window/Level to the original values, double-click the image.
4. The Ruler tool displays a measurement of the distance between two points. To move the
measurement line, click and drag the line to the new location.
5. The Fit-to-Viewport tool fits the image within the image tile.
6. The View Actual Pixels tool displays the image in full resolution.
7. The Mirror tool reverses (mirrors) the image.
8. The Invert tool changes blacks to white and whites to black.
9. The Multi-Up Display tool selects the number of tiles to display.
10. The Image Tile Advance tool sets the active Multi-Up tile.
11. The Enhanced Visualization tool adjusts the image sharpness with a slider.
12. The Patient Information tool activates the patient information display.
13. The Window/Level Fine Adjustment
tool allows the entry of specified values for contrast and
brightness, also allows a reset to the original default Window/Level values.
14. The Pre-defined Window/Level tools set the values most used.
15. The Camera button captures a snapshot of the image display area and adds the snapshot to
the current procedure.
16. The Reset tool returns an enhanced image to the original state and keeps on-screen drawings
and annotations. Your Service Engineer can set this tool to return to the original state without
drawings or annotations.
