COMPONENT IDENTIFICATION
REMOTE CONTROL BOX
PANEL-MOUNT TYPE (R2 type)
SIDE-MOUNT TYPE (R1 type)
POWER TRIM/TILT SWITCH
OVER HEAT
WARNING LIGHT
(RED)
EMERGENCY STOP
SWITCH LANYARD
EMERGENCY
STOP SWITCH
ENGINE SWITCH
BUZZER
(inside of the box)
REMOTE
CONTROL LEVER
NEUTRAL RELEASE LEVER
FAST IDLE LEVER
(with choke function)
REMOTE CONTROL LEVER
FAST IDLE BUTTON
POWER TRIM/
TILT SWITCH
NEUTRAL RELEASE
LEVER
OIL PRESSURE
INDICATOR
LIGHT (GREEN)
EMERGENCY STOP
SWITCH CLIP
