16
COMPONENT IDENTIFICATION
TOP-MOUNT TYPE (R3 type) SWITCH PANEL
(SINGLE MOTOR TYPE) (DUAL MOTOR TYPE)
(PANEL-MOUNT, TOP-MOUNT)
POWER TRIM/
TILT SWITCH
BUZZER
ENGINE SWITCH
EMERGENCY STOP
SWITCH
EMERGENCY STOP
SWITCH CLIP
CHOKE
SWITCH
OVERHEAT
WARNING
LIGHT (RED)
FAST IDLE BUTTON
POWER TRIM/TILT
SWITCH (LEFT)
POWER TRIM/TILT
SWITCH (RIGHT)
REMOTE CONTROL
LEVERS
FAST IDLE BUTTON
OIL PRESSURE
INDICATOR LIGHT
(GREEN)
EMERGENCY STOP
SWITCH LANYARD
REMOTE CONTROL
LEVER
