Honeywell 30 Series User Guide

30 Series Network Video Recorder User Guide
22
Figure 5-4 Credentials
2. Enter the username and password. Click Log in and the search interface is displayed:
Figure 5-5 Search
3. Select cameras (up to 4 cameras) in the camera list and the days with recorded clips will
be highlighted in blue. The date highlighted in green indicates today.
4. Click to set up the layout when more than one cameras are played back
simultaneously.
5. Double-click on a day to begin playback and search.

Honeywell 30 Series Specifications

General

Video Compression	H.264
Series	30 Series
Category	Security Camera
Night Vision	Yes
Power Source	Wired
Motion Detection	Yes
Weather Resistance	Yes
Lens	Fixed
Storage	MicroSD card (up to 128GB)
