Layout
By default, 5 typical layouts are provided for the user. They include: 1x1, 2x2,
3x3, 1V+3, and 1M+5. System default is the 2x2 layout. Cameras that do not fit into
the first page of a layout, say, a 3x3 layout, will be displayed on the succeeding layout pages.
Figure 7-5 Layout
Each functional button on the screen is activated by a mouse hover. For example, the below
states designate user's operation on a button:
• : not selected.
• : moused over and is ready for selection.
• : selected and is taking effects.
There are another 4 user layouts that can be individually configured. An administrator can
insert camera views into these layouts and save the configuration. These user layouts can be
seen by all users.
If you click the Rotate button before the configuration changes can be saved, your
configuration changes will be lost.
Layout Contents
A few functional buttons are available on the Layout contents page.
Table 7-2 Layout Contents
Clears all view cells on the current layout.
Full view: extends the view cells on the current layout to the full of the screen.
Exit full view. It is showed at the left side of the full view window.
Rotate: the rotate function lets system display successive layout pages by
the intervals of 10 seconds. The layout page that does not contain camera
views will be skipped.
To Next Page
