109
See the following table for the data type matching between the
ControlEdge 900 controller variables and Experion Server
parameters.
Data type in ControlEdge 900
controller
Data type in Experion
IEC_BOOL BOOLEAN
IEC_SINT INT8
IEC_INT INT16
IEC_DINT INT32
IEC_USINT UINIT8
IEC_UINT UINT16
IEC_UDINT UINT32
IEC_REAL FLOAT32
IEC_LREAL FLOAT64
IEC_BYTE UINT8
IEC_WORD UINT16
IEC_DWORD UINT32
IEC_ULINT UINT64
IEC_LWORD UINT64
IEC_STRING STRING
IEC_STRUCT See Note 1 below.
Note 1: Structure is a data type of I/O variable, so you should
create a single variable for each parameter in the structure for
CDA communication.
a. Click IEC Programming Workspace from the toolbar.
b. Perform either of the following methods to select CDA.
l From the variable sheets, select CDA.
Chapter 6 - Communication
