79
l If you do not select the Interactive mode , the firmware will be
upgraded directly after the transfer. The controller will be
stopped without any prompt.
5. Click Proceed with Upgrade to continue.
6. From the Release Number list, elect the target release module. The
target firmware version is displayed.
7. Click Next. The target firmware name, state and version are
displayed.
8. Click Next to transfer and upgrade the fireware.
9. After the upgrade is completed, a dialog appears. You can check
which Expansion I/O is upgraded successfully, which one is failed.
10. Click OK.
Upgrading the FDAP and field device firmware
via Wireless
The FDAPs and field devices have radio firmware that can be
upgraded. Some field devices may have a separate application
firmware, which handles the functioning of the sensor in the device.
This can also be upgraded over the wireless network. For more
information about upgrading the firmware of field devices, refer to
the field device vendor’s documentation. Honeywell field devices
usually have separate firmware files for radio firmware and
application firmware. FDAPs have only radio firmware.
ATTENTION: If either of the field device and FDAP is upgraded
to OW R300, the other one should be upgraded too.
Upgrading the field device firmware
The devices at the farthest hop level must be upgraded first.
To upgrade a field device firmware
1. On the Selection Panel, select the field device. You can select
multiple devices of the same type using the Selection Panel. Click
and hold SHIFT key on the keyboard and select multiple items in a
successive list. Click and hold CTRL key on the keyboard and
select multiple items not in succession.
Chapter 5 - Operating
