Configuring hardware
Setting controller name
You can set a new name for a controller.
1. From the Home Page, under Controller and Programming, click Set
Controller Name.
2. Enter the desired name for the controller, and click Save.
If using Experion integration with ControlEdge 900 or 2020
controller, this name is used to identify the controller during Experion
configuration.î
Configuring the controller IP address
The first thing you will normally want to do is set the IP address for
the controller. The following steps describe how to configure a fixed
IP address starting with creating a new project.
The following table lists the factory default network settings. If your
controller has been previously configured, these settings may have
been changed.
Port Default setting
ETH1 IP address is dynamically assigned from a DHCP server.
If no DHCP server is found by the controller, an IPv4 link-local address will be
assigned (169.254.x.x).
ETH2 Static IP address: 192.168.1.50
Table 4-1: Factory default network settings of the non-redundant controller
Port Default setting
ETH1 IP address is dynamically assigned from a DHCP server.
If no DHCP server is found by the controller, an IPv4 link-local address will be
assigned (169.254.x.x).
The secondary controller IP address is incremented by 1 from the primary
controller IP address.
ETH2 The primary controller static IP address: 192.168.1.50
Table 4-2: Factory default network settings of the redundant controller
44
Chapter 4 - Software
