configuration, and upgrading the firmware for over ten
minutes.
Downloading a project to the controller
After compiling a project without any error, you have to download the
project to the controller.
Before downloading the project to the controller, you have to ensure:
n The project is opened in ControlEdge Builder.
n The project is compiled without any error. See "Compiling a
project" on page65 for more information.
n Log in as the Administrator or Engineer to connect the target
controller. See "Connecting a controller" on the previous page for
more information.
n The primary CPM is connected if the controller is redundant.
n See "Connecting a controller" on the previous page for more
information.
To download a project
1. From the Home Page, click Download. A eclrRes window appears:
For more information about the items in the eclrRes window, see
the embedded online help. Select Help > Contents, and search for
PLC state machine to display the corresponding content.
2. A Download confirmation dialog appears to make sure you want
to download. Click Yes.
ATTENTION: If you want to upload this project in the future,
you should select Download the project archive, and a zip file
of the archived project will be stored in the controller.
3. There are two scenarios:
l If the controller does not contain any project or the project you
are going to download has a different name with the project is
already stored in the controller, you should click Stop in the
eclrRes window to stop the program execution. Then click
Download in the eclrRes window to continue the download.
l If the project with the same name is already stored in the
68
Chapter 5 - Operating
