l From the variable properties dialog, select CDA.
6. Click Make to compile the configuration to the controller.
Publishing to Experion
For peer to peer connection to C300 or other Experion CEE based
controller, you need to publish the configuration to the Experion
Server through CDA.
There are three installation scenarios that need to be considered for
the behavior of the Publish to Experion function.
n Publishing when ControlEdge Builder is launched from
Configuration Studio
n Publishing when ControlEdge Builder is launched separately on
an Experion node
n Publishing when ControlEdge Builder is launched on non-
Experion node
In this scenario, the “Experion client components” optional
installation package must be installed from the Experion
Installation Media which you want to communicate with for the
Publish to Experion function to work.
ControlEdge Builder is installed on a same version of Microsoft
Windows that is supported for either Experion Client or Server that
you want to communicate with.
It is recommended to publish configuration when ControlEdge
Builder is launched from Configuration studio.
From the Home Page of ControlEdge Builder, click Publish to Experion
under I/O and Communications. The project configuration will be
published to Experion directly.
110
Chapter 6 - Communication
