TIP: It is recommended to select and accept up to three
devices at a time.
2. Click one of the following icons as required in the Upgrade group
from the Ribbon Bar. Application firmware must be upgraded
before upgrading the radio firmware.
l Application: To upgrade the application firmware of the selected
field device.
l Radio: To upgrade the radio firmware of the selected field
device.
The Application/Radio Firmware Upgrade dialog box appears.
3. Depending on the firmware type, the available upgrade files
appear by default. Select the required file from the list of upgrade
files. If the file is not available in the list, perform the following
steps.
a. Click Add to browse to the directory location of the firmware
upgrade file.
b. Select the target firmware upgrade file, and click Open.
4. Click Upgrade. The Application/Radio Firmware Upgrade dialog box
closes. The Firmware Upgrade Status dialog box displaying the
status of the upgrade appears. Closing the dialog box allows the
upgrade operation to run in the background.
Once the upgrade is complete, the status column displays the
status as complete. If firmware upgrade fails for a device, you can
abort the upgrade and start again. To abort firmware upgrade for
individual devices, click the abort button next to the status
indicator.
See the following tips for other operations:
l To abort any firmware upgrade operation, click the Abort
Upgrade icon besides the upgrade status.
l To remove the devices whose firmware was upgraded
successfully, click the Clear Upgrade icon besides the upgrade
status.
l The field device will be rebooted after the field device radio
firmware upgraded successfully.
5. Close the Firmware Upgrade Status dialog box.
6. Verify the upgraded version of the field device firmware as follows:
80
Chapter 5 - Operating
