Honeywell ECS Series User Manual

LS10143-001SK-E Programming Overview
8-22
Point
(cont.)
ECS-VCM/ECS-
RVM/ECS/NVCM
Enter Pt /Select Function SWITCH
MANUAL RELEASE
Section 9.5.7
INTERLOCK
STATUS POINT
ECS INPUT
ECS TAMPER
ECS SUPERVISORY
VOICE AUX STATUS 1-2
BACKGROUND MUSIC
VOICE AUX ECS 1-4
System
Options
Communication
Options
Auto Time Test
Set the Hour
*02:00AM
Section 9.6.1.1
Set the Minutes
Select AM/PM
Enter Interval
24 hrs,12 hrs, *6
hrs, 4 hrs
Phone Lines
For each phone line (1 & 2) select:
Dialing Prefix Up to 9 digits *none Section 9.6.1.2
# of Answer Rings Range: 00-15 *06
Number of rings
before panel
answers a call
from a computer
Section 9.6.1.2
Select Dialing Option
TT
*TT
Touch Tone
TT/PL
TouchTone
alternating with
pulse see
Section 9.6.1.2
PULSE Pulse dialing
Rotary Pulse Format
U = 60/40
*U
Section 9.6.1.2E = 66/34
Dial Tone Disabled Y or N *N
Monitor Line Y or N *N Section 9.6.1.2
Answering Machine
Bypass
Y or N *N Section 9.6.1.2
Phone Line Unused Y or N *N Section 9.6.1.2
Edit Ethernet
IP Address
Section 9.6.1.3
Subn Mask
SubNet
Default Gateway
DHCP Enable
AlarmNet Timers
Ethernet Supervise
75 sec, 90 Sec,
3 min, 5 min, 1
hr, 24 hrs, 30
days, None
*5 Minutes
Section 9.6.1.4
Cellular Supervise
24Hrs, 30 days,
none
*24 Hours
Old Alarm Time
10 min, 15 min,
30 Minutes, 1 hr,
2 hrs, 4 hrs, 8
hrs, 12 hrs,
24hrs, none
*30 Minutes
Menu Options/Defaults Comments
