Serial essernet
®
interface (SEI1)
70 FB 798819 / 05.18
Zone range
This menu is used to enter the zone range of the FACPs which are connected via the essenet
.
These intervals are identical to the zone intervals in all other FACPs connected to the essernet
.
Fig. 26: Zone range
The zone and control zone numbers must be unique and must not be used twice in
the essernet
and the sub nets.
Selection of the FACP number.
This number must be identical with the
address set at the essernet
micro modules of
the panel (max. range 1 to 31).
