Accessing the Camera
5
Upgrading the Camera’s Firmware
Before you begin using your camera, make sure you have the latest firmware installed. You
can upgrade a single camera or multiple cameras at the same time.
To upgrade a single camera:
1. Select the camera that you want to upgrade from the devices list.
2. Click the Upgrade tab.
3. Click Browse, navigate to the directory that contains the firmware file (.bin), select the file,
and then click Open. The firmware file appears in the Target File field.
4. Click Upgrade. When the upgrade is complete, the camera will reboot.
To upgrade multiple cameras at the same time:
1. In the left-most pane of the IPC Tool utility, click Batch Setting.
2. Select all the cameras that you want to upgrade from the devices list.
3. Click the Upgrade tab.
4. Click Browse, navigate to the directory that contains the firmware file (.bin), select the file,
and then click Open. The firmware file appears in the Target File field.
5. Click Upgrade. When the upgrade is complete, the cameras will reboot.
Accessing the Camera from a Web Browser
To access the camera from a web browser:
1. Select the camera that you want to access from the devices list. The camera must be
online .
2. On the Device Information tab, click Web Page. The web client opens in your default
browser.

Honeywell HC30W45R3 Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired & Wireless
Wide Dynamic Range (WDR)	Yes
Maximum operating distance	30 m
IK code	IK10
Form factor	Spherical
Mounting type	Ceiling/wall
Product color	Black, White
International Protection (IP) code	IP66
White balance	Auto, Manual
Minimum illumination	0.03 lx
Bit rate control	Constant Bit Rate (CBR)
Total megapixels	5 MP
Gain control type	Auto
Maximum resolution	2560 x 1920 pixels
Video formats supported	H.264, H.265
Analog signal format system	NTSC, PAL
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 960, 1600 x 1200 (UXGA), 2048 x 1536 (QXGA), 2560 x 1920
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.7 \
Lens diameter	2.8 mm
Fixed focal length	2 mm
Maximum aperture number	2
Wi-Fi	No
Number of users	10 user(s)
Ethernet interface type	Gigabit Ethernet
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	6.49 W
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 90 %
Windows operating systems supported	Windows 10, Windows 7

Weight and Dimensions

Depth	89.51 mm
Width	117.11 mm
Weight	540 g
Package weight	880 g
