Logging In and Viewing Live Video
13
Figure 3-10 Fisheye Display Mode
Table 3-2 Fisheye Display Mode
Display Mode Description
1O One Original fisheye view
1P One Panoramic view
1R One Regional view
1P2R One Panoramic and two Regional views
(Wall mount)
2P Two Panoramic views
1P3R One Panoramic and three Regional views
(Wall mount)
1O3R One Original and three Regional views
4R Four Regional views
4R PRO Four Regional views interactively displayed
when the field of view changes in any of the
views
1O8R One Original and eight Regional views
1O (One Original) Display Mode
When mounted on a ceiling, the fisheye camera can cover an approximate of 64 m²
surveillance area (installed at a height of approximately 3 meters), while still keeping details in
videos with recognizable facial features of people passing through the area.
The 1O view is especially adequate for taking an overview glimpse of the surveillance area
when mounted on the ceiling.
