Configuring Video Analytics
57
The Item Size Indicator will rise or fall depending on the variation between sequential images.
When motions are detected by the camera and are considered to exceed the preset threshold,
the red bar rises. Meanwhile, the motion detection window will be outlined in red.
Photos or videos can be captured instantly and configured to be sent to a remote server (i.e.
via an Email). For more information on how to configure an event setting, see Configuring
Event Settings on page 60.
A green bar indicates that even though motions have been detected, the event has not been
triggered because the image variations still fall under the preset threshold.
Figure 6-3 Item Size Indicator
Smaller than the item size Larger than the item size
Intrusion Detection
The Intrusion Detection detects people motions in customized windows. If a people motion is
detected, the frame of the customized window will become flashing red.
Figure 6-4 Intrusion Detection
To enable intrusion detection:
