Performance Series IP Camera Software Configuration Guide
78
• Priority: Select the relative importance of this recording (High, Normal, or Low). Recording
with a higher priority setting will be executed first.
• Source: Select a video stream as the recording source.
Note
To enable recording notification, configure Event settings first, see
Configuring Event Settings on page 60.
Setting up a Recording
To set up a recording:
1. Select a trigger source.
Schedule: The server will start to record files on the local storage or network storage
(NAS).
Network fail: Since network fail, the server will start to record files on the local storage (SD
card).
2. Select a destination (SD or NAS) for the recorded video files. If you have not configured a
NAS server, see Adding NAS Server on page 79.
• Capacity: You can choose either the entire free space available or limit the reserved
space. The recording size limit must be larger than the reserved amount for cyclic
recording. The reserved space is a small amount of space used only for the
transaction stage when the capacity is about to be used up or recycled.
• Enable cyclic recording: If you check this item, when the maximum capacity is
reached, the oldest file will be overwritten by the latest one. The reserved amount is
reserved for the transaction stage when the storage space is about to be full and new
data arrives. The minimum for the reserved space must be larger than 15 MegaBytes.
• Recording file management: You can manually assign the Maximum duration and the
Maximum file size for each recording footage. You may need to stitch individual files
together under some circumstances. You may also designate a file name prefix by
filling in the responsive text field.
• File name prefix: Enter the text that will be appended to the front of the file name.
If you want to enable recording notification, click Event to configure event triggering settings.
For more information, see Configuring Event Settings on page 60.
When completed, select Enable this recording. Click Save to enable the setting and click
Close to exit this page. When the system begins recording, it will send the recorded files to the
network storage. The new recording name will be displayed on the recording settings page as
shown below.
To remove a recording setting from the page, click Delete.

Honeywell HC30W45R3 Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired & Wireless
Wide Dynamic Range (WDR)	Yes
Maximum operating distance	30 m
IK code	IK10
Form factor	Spherical
Mounting type	Ceiling/wall
Product color	Black, White
International Protection (IP) code	IP66
White balance	Auto, Manual
Minimum illumination	0.03 lx
Bit rate control	Constant Bit Rate (CBR)
Total megapixels	5 MP
Gain control type	Auto
Maximum resolution	2560 x 1920 pixels
Video formats supported	H.264, H.265
Analog signal format system	NTSC, PAL
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 960, 1600 x 1200 (UXGA), 2048 x 1536 (QXGA), 2560 x 1920
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.7 \
Lens diameter	2.8 mm
Fixed focal length	2 mm
Maximum aperture number	2
Wi-Fi	No
Number of users	10 user(s)
Ethernet interface type	Gigabit Ethernet
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	6.49 W
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 90 %
Windows operating systems supported	Windows 10, Windows 7

Weight and Dimensions

Depth	89.51 mm
Width	117.11 mm
Weight	540 g
Package weight	880 g
