Honeywell HC30W45R3 Configuration Guide

Performance Series IP Camera Software Configuration Guide
46
Figure 5-4 IPv6 Address
Follow the steps below to link to an IPv6 address:
1. Open your web browser.
2. Enter the link-global or link-local IPv6 address in the address bar of your web browser.
3. The format should be: http://[2001:0c08:2500:0002:0202:d1ff:fe04:65f4]/
4. Press Enter on the keyboard or click Refresh button to refresh the webpage.
Note
If you have a Secondary HTTP port (the default value is 8080), you
can also link to the webpage using the following address format:
(see Configuring Streaming Protocols on page 46 for detailed
information.)
Manually setup the IP address: Select this option to manually set up IPv6 settings if your
network environment does not have DHCPv6 server and router advertisements-enabled
routers. If you check this item, the following blanks will be displayed for you to enter the
corresponding information:
Figure 5-5 Manually setup IP Address
Configuring Streaming Protocols
Go to SetupNetwork SetupStreaming Protocols.
Link-global IPv6 address/network mask
Link-local IPv6 address/network mask

Honeywell HC30W45R3 Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired & Wireless
Wide Dynamic Range (WDR)	Yes
Maximum operating distance	30 m
IK code	IK10
Form factor	Spherical
Mounting type	Ceiling/wall
Product color	Black, White
International Protection (IP) code	IP66
White balance	Auto, Manual
Minimum illumination	0.03 lx
Bit rate control	Constant Bit Rate (CBR)
Total megapixels	5 MP
Gain control type	Auto
Maximum resolution	2560 x 1920 pixels
Video formats supported	H.264, H.265
Analog signal format system	NTSC, PAL
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 960, 1600 x 1200 (UXGA), 2048 x 1536 (QXGA), 2560 x 1920
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.7 \
Lens diameter	2.8 mm
Fixed focal length	2 mm
Maximum aperture number	2
Wi-Fi	No
Number of users	10 user(s)
Ethernet interface type	Gigabit Ethernet
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	6.49 W
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 90 %
Windows operating systems supported	Windows 10, Windows 7

Weight and Dimensions

Depth	89.51 mm
Width	117.11 mm
Weight	540 g
Package weight	880 g
