Honeywell HF680 Series User Manual

HF680 Series User Guide 135
Baud Rate 300 BPS 232BAD0 22
600 BPS 232BAD1 22
1200 BPS 232BAD2 22
2400 BPS 232BAD3 22
4800 BPS 232BAD4 22
9600 BPS 232BAD5 23
19200 BPS 232BAD6 23
38400 BPS 232BAD7 23
57600 BPS 232BAD8 23
*115200 BPS 232BAD9 23
Word Length: Data Bits, Stop Bits,
and Parity
7 Data, 1 Stop, Parity Even
232WRD3
23
7 Data, 1 Stop, Parity None 232WRD0 23
7 Data, 1 Stop, Parity Odd 232WRD6 23
7 Data, 2 Stop, Parity Even 232WRD4 23
7 Data, 2 Stop, Parity None 232WRD1 23
7 Data, 2 Stop, Parity Odd 232WRD7 24
8 Data, 1 Stop, Parity Even 232WRD5 24
*8 Data, 1 Stop, Parity None 232WRD2 24
8 Data, 1 Stop, Parity Odd 232WRD8 24
RS232 Receiver Time-out Range 0 - 300 seconds 232LPT### 24
RS232 Handshaking *RTS/CTS Off 232CTS0 25
Flow Control, No Timeout 232CTS1 25
Two-Direction Flow Control 232CTS2 25
Flow Control with Timeout 232CTS3 25
RS232 Timeout 232DEL#### 25
*XON/XOFF Off 232XON0 25
XON/XOFF On 232XON1 25
*ACK/NAK Off 232ACK0 26
ACK/NAK On 232ACK1 26
Scanner-Bioptic Packet Mode *Packet Mode Off 232PKT0 26
Packet Mode On 232PKT2 26
Scanner-Bioptic ACK/NAK Mode *Bioptic ACK/NAK Off 232NAK0 27
Bioptic ACK/NAK On 232NAK1 27
Scanner-Bioptic ACK/NAK
Timeout
ACK/NAK Timeout
*5100
232DLK##### 27
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric
entry
Page

Honeywell HF680 Series Specifications

General

Image Sensor	CMOS
Symbol Contrast	20% minimum reflectance difference
Interface	USB, RS-232, Keyboard Wedge
Operating Temperature	32°F to 122°F (0°C to 50°C)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% (non-condensing)
Light Levels	0 to 100, 000 lux
Supported Barcodes	UPC/EAN, Code 39, Code 128, QR Code, Data Matrix
