154 HF680 Series User Guide
Guaranteed Performance
Standard Cable Pinouts
Note: The following pin assignments are not compatible with Honeywell legacy products.
Use of a cable with improper pin assignments may lead to damage to the unit. Use of
any cables not provided by the manufacturer may result in damage not covered by
your warranty.
Focus
Symbology
Near
Distance
Far
Distance
5 mil Code 39 in. .39 2.76
mm 10 70
6.7 mil PDF in. .79 3.15
mm 20 80
10 mil Data Matrix in. .79 3.74
mm 20 95
13 mil UPC-A in. .79 6.3
mm 20 160
20 mil Code 39 in. .59 9.25
mm 15 235
20 mil QR Code in. .79 7.68
mm 20 195
*Resolution: 1D: 3mil
2D: 6.7 mil
*Performance may be impacted by barcode qu ality.
