Honeywell HF680 Series User Manual

52 HF680 Series User Guide
Intermessage Delay
An intermessage delay of up to 5000 milliseconds (in 5ms increments) may be
placed between each scan transmission. Scan the Intermessage Delay barcode
below, then scan the number of 5ms delays, and the Save barcode using the
Programming Chart.
To remove this delay, scan the Intermessage Delay barcode, then set the number
of delays to 0. Scan the Save barcode using the Programming Chart.
2nd Scan Transmission1st Scan Transmission
Intermessage Delay
Intermessage Delay

Honeywell HF680 Series Specifications

General

Image Sensor	CMOS
Symbol Contrast	20% minimum reflectance difference
Interface	USB, RS-232, Keyboard Wedge
Operating Temperature	32°F to 122°F (0°C to 50°C)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% (non-condensing)
Light Levels	0 to 100, 000 lux
Supported Barcodes	UPC/EAN, Code 39, Code 128, QR Code, Data Matrix
