Honeywell HF680 Series User Manual

HF680 Series User Guide 137
Presentation Centering Window Presentation Centering On PDCWIN1 36
*Presentation Centering Off PDCWIN0 36
Top of Presentation Centering Window
(*40%)
PDCTOP### 36
Bottom of Presentation Centering
Window (*60%)
PDCBOT### 37
Left of Presentation Centering Window
(*40%)
PDCLFT### 37
Right of Presentation Centering Window
(*60%)
PDCRGT### 37
Streaming Presentation Mode *Normal TRGMOD8;PDCEMX500;
PDCGMX8
37
Enhanced TRGMOD8;PDCEMX150;
PDCGMX12
37
Read Mode *Paper and Screen ILLMOD1 38
Paper Only ILLMOD0 38
Screen Only ILLMOD2 38
Poor Quality Codes Poor Quality 1D Reading On DECLDI1 38
*Poor Quality 1D Reading Off DECLDI0 38
Poor Quality PDF Reading On PDFXPR10 39
*Poor Quality PDF Reading Off PDFXPR0 39
Reread Delay Short (500 ms) DLYRRD500 39
*Medium (750 ms) DLYRRD750 39
Long (1000 ms) DLYRRD1000 39
Extra Long (2000 ms) DLYRRD2000 39
User-Specified Reread Delay Range 0 - 30,000 ms DLYRRD##### 40
2D Reread Delay *2D Reread Delay Off DLY2RR0 40
Short (1000ms) DLY2RR1000 40
Medium (2000ms) DLY2RR2000 40
Long (3000ms) DLY2RR3000 40
Extra Long (4000ms) DLY2RR4000 40
Character Activation Mode *Off HSTCEN0 40
On HSTCEN1 40
Activation Character HSTACH## 41
Do Not End Character Activation After
Good Read
HSTCGD0 41
*End Character Activation After Good
Read
HSTCGD1 41
Character Activation Timeout (Range 1 -
65525) *5000 ms
HSTCDT##### 42
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric
entry
Page

Honeywell HF680 Series Specifications

General

Image Sensor	CMOS
Symbol Contrast	20% minimum reflectance difference
Interface	USB, RS-232, Keyboard Wedge
Operating Temperature	32°F to 122°F (0°C to 50°C)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% (non-condensing)
Light Levels	0 to 100, 000 lux
Supported Barcodes	UPC/EAN, Code 39, Code 128, QR Code, Data Matrix
